Aohua Soybean Peeler Machine

2025-05-08

Product Introduction
Soybean peeling machine is based on the unique structural characteristics of soybeans and peas, professional research and development of large soybean soybean peeling machine.Bean peeling machine is a multi-functional peeling machine, using sand roller structure to destroy grain endosperm less, high yield, up to 2 tons per hour processing capacity. The removal rate of bean reached more than 98%.

It is mainly composed of feeding mechanism, screw propeller, peeling chamber, emery roller, transmission mechanism, aggregate hopper, discharge device, dust collector and other components.

The main It is widely used in various soybean product factories: such as soybean milk factory, bean curd factory, tofu factory, and so on. Manufacturers. For soybean product manufacturers raw food hygiene, reduce food contamination.


Working Principle
1.Material is conveyed by the screw propeller to the peeling chamber which is at the machine's core part.
2.The high-speed rotation emery roll rubs the beans bran continuously, which destroys the bonding strength between the bean bran
and kernels, and makes bean bran separated gradually.
3.Then the material is conveyed to the outlet of the equipment and the peeling process is finished.
4.It connects with efficient aspiration system, which ensures the reliable effect for bean bran discharging.
