Biomass Chain Furnace

Applicable materials: lignin, sludge drying, paper-making black liquor, pharmaceutical waste liquid treatment, etc., poly-aluminium chloride, quartz sand, alumina, chemical additives, water purifier, iron sulfate, etc., lignite, briquette, wood drying, wine lees, feed, fertilizers: compound fertilizer, mono-ammonium phosphate, diammonium phosphate, potassium chloride, magnesium sulfate, potassium sulfate, etc., ceramic fiber, insulation board, insulation cotton, ultrafine powder, gypsum, quartz sand, etc.
The pulverized coal hot air furnace consists of five parts: the combustion furnace body, the fuel lifting mechanism, the air distribution and smoke return device, the dust removal or indirect heat exchange and the electrical control cabinet.

The chain-discharge hot air furnace uses coal as fuel. Through the coal hopper and coal delivery mechanism, a fixed amount of coal is delivered into the combustion chamber. At the same time, a combustion-supporting air with a certain pressure is delivered to make it fully burn and produce a large amount of hot air. Then, the high-temperature airflow is separated from the dust through the cyclone dust removal. In order to achieve a high-temperature gas heat source that meets production requirements, the chain-discharge hot air furnace is equipped with automatic control systems such as temperature, air volume and speed regulation.
