Coal Briquette Machine

Product Description
The briquette press is a device that presses briquette or coal powder into balls. It is widely used to reduce dust, control bulk density, return and improve transportation characteristics.

We're here to help: Easy ways to get the answers you need.

GET PRICE SEND EMAIL
Share With:

Products list

inquery

contact us

hot products

  • Maize Mill Equipment

  • Flour Mill Machine

  • Plansifter

  • Double Bins Plansifter

  • 1
  • 2
  • 3
  • 4

description



The briquette press is a device that presses briquette or coal powder into balls. It is widely used to reduce dust, control bulk density, return and improve transportation characteristics.It is now used all over the world, which not only increases the benefits of enterprises, but also reduces the waste of resources.

Product Structure of Coal Briquette Machine:
1. The feeding part is mainly used to achieve quantitative feeding to ensure that the material enters the roller space evenly.
2. Transmission part, the main transmission system is: motor---triangular belt---reducer---open gear---roller.
3. The forming part mainly refers to the main machine part, and the core part is the roller.


When the briquette press machine is working, the main machine is powered by an electromagnetic speed regulating motor, which is transmitted to the driving shaft through a pulley, a cylindrical gear reducer, and a rod pin coupling. The driving shaft and the passive shaft are ensured to run synchronously through open gears. A hydraulic device is installed behind the passive bearing seat. The screw feeder is driven by an electromagnetic speed regulating motor, which rotates through a pulley and a worm reducer to force the pressed material into the main feed port. Due to the constant torque characteristics of the electromagnetic speed regulating motor, when the pressing amount of the screw feeder is equal to the amount of material required by the main machine, a constant feeding pressure can be maintained to stabilize the quality of the pellets.




Model

Speed reducer

Ratio

Roller size

Rotation speed

(r/min)

Motor model

Motor power

(kw)

Capacity(t/h)

Dimension(m)

YHQ290

ZQ350

1:23.24

290*220

20-25

Y132M-4

5.5

2-3

1.2*1*1.4

YHQ360

ZQ350

1:31.5

360*250

15-17

Y132M-4

7.5

3-5

2.26*1.53*1.98

YHQ400

ZQ400

1:31.5

400*250

15-17

Y160M-4

11

4-7

2.3*1.38*1.96

YHQ500

ZQ500

1:31.5

500*300

15-17

Y180L-4

22

8-10

2.61*1.75*2.35

YHQ650

ZQ650

1:31.5

650*300

12-16

Y1200L-4

30

12-20

3.42*2*2.4

YHQ750

ZQ750

1:31.5

750*380

12-15

Y225M-4

45-55

25-30

3.7*2.55*2.6

YHQ850

ZQ850

1:31.5

850*380

10-15

Y250M-4

55-75

35-40

3.9*2.6*2.7

YHQ1000

ZQ1000

1:31.5

1000*530

10-13

Y315S-4

110-132

40-45

4*2.8*2.8

1. Inner packing: Plastic film
2. Outside packing: Container/Wooden box
3. Shipping: By sea in QINGDAO port or according to your demand
