2022 Wheat Paddy Maize Corn Grain Sesame Seed Bean Selecting Cleaning Sorting Machine
2022 Wheat Paddy Maize Corn Grain Sesame Seed Bean Selecting Cleaning Sorting Machine
1) Function: pre-cleaning and cleaning raw grains and seeds, grading by size, removing large and small impurities, and dust with aspirator system.
2) Application: raw grains and seeds.
3) Capacity: 1~120 t/h for pre-cleaning, 1~25t/h for cleaning.
Contact US
Get Price
Share:
Content
2022 Wheat Paddy Maize Corn Grain Sesame Seed Bean Selecting Cleaning Sorting Machine
Model | Screen Size
(W x L) (cm2) |
Capacity
on Wheat (t/h) |
Screen Angle
(°) |
Power
(kW) |
Weight (kg) | Size
(L x W x H) (mm) |
Air Suction Volume
(m3/min)
|
||
Pre-cleaning | Cleaning | Pre-cleaning | Cleaning | ||||||
TQLZ40x80 | 40×80 | 3 | 2 | 6 | 6 | 2×0.15 | 190 | 1300x820x1095 | 22 |
TQLZ60x100 | 60×100 | 20 | 5 | 6 | 6 | 2×0.25 | 360 | 1640x1550x1455 | 32 |
TQLZ100x100 | 100×100 | 30 | 8 | 6 | 6 | 2×0.25 | 420 | 1640x1610x1455 | 52 |
TQLZ100x150 | 100×150 | 50 | 12 | 9 | 6 | 2×0.37 | 520 | 2140x1610x1455 | 80 |
TQLZ100x200 | 100×200 | 60 | 16 | 12 | 6 | 2×0.37 | 540 | 2640x1610x1455 | 90 |
TQLZ150x100 | 150×100 | 50 | 12 | 6 | 6 | 2×0.37 | 540 | 1640x2160x1455 | 80 |
TQLZ150x150 | 150×150 | 75 | 16 | 9 | 6 | 2×0.75 | 630 | 2140x2160x1455 | 110 |
TQLZ150x200 | 150×200 | 100 | 24 | 12 | 6 | 2×0.75 | 650 | 2640x2160x1455 | 135 |
TQLZ180x200 | 180×200 | 120 | 28 | 12 | 6 | 2×1.1 | 1000 | 2740x2510x1980 | 160 |
