Professional wheat cleaning machine maize processing machine
TQLZ Vibro Separator
1) Function: pre-cleaning and cleaning raw grains and seeds, grading by size, removing large and small impurities, and dust with aspirator system.
2) Application: raw grains and seeds
3) Capacity: 1~120 t/h for pre-cleaning, 1~25t/h for cleaning
Professional wheat cleaning machine maize processing machine
product features
– Low power consumption
– Fast and easy to change sieves
– The inclination degree of the sieves is adjustable.
– With rubber balls under the sieves to reduce blocking of sieves
– No lubrication points can minimize the maintenance requirements of the machine.
– In order to optimize the cleaning effect, an optional aspiration channel or air recycling aspirator can be employed to match with the machine. In this way, the light impurities such as dust and husks can also be removed as well.
– Widely used to process wheat, corn (maize), oats, buckwheat, oilseeds and rice in wheat flour mills, feed mills, seed cleaning plants and rice mills.
Technical parameter
Model |
Screen Size
(W x L) (cm2) |
Capacity
on Wheat (t/h) |
Screen Angle
(°) |
Power
(kW) |
Weight (kg) | Size
(L x W x H) (mm) |
Air Suction Volume
(m3/min)
|
||
Pre-cleaning | Cleaning | Pre-cleaning | Cleaning | ||||||
TQLZ40x80 | 40×80 | 3 | 2 | 6 | 6 | 2×0.15 | 190 | 1300x820x1095 | 22 |
TQLZ60x100 | 60×100 | 20 | 5 | 6 | 6 | 2×0.25 | 360 | 1640x1550x1455 | 32 |
TQLZ100x100 | 100×100 | 30 | 8 | 6 | 6 | 2×0.25 | 420 | 1640x1610x1455 | 52 |
TQLZ100x150 | 100×150 | 50 | 12 | 9 | 6 | 2×0.37 | 520 | 2140x1610x1455 | 80 |
TQLZ100x200 | 100×200 | 60 | 16 | 12 | 6 | 2×0.37 | 540 | 2640x1610x1455 | 90 |
TQLZ150x100 | 150×100 | 50 | 12 | 6 | 6 | 2×0.37 | 540 | 1640x2160x1455 | 80 |
TQLZ150x150 | 150×150 | 75 | 16 | 9 | 6 | 2×0.75 | 630 | 2140x2160x1455 | 110 |
TQLZ150x200 | 150×200 | 100 | 24 | 12 | 6 | 2×0.75 | 650 | 2640x2160x1455 | 135 |
TQLZ180x200 | 180×200 | 120 | 28 | 12 | 6 | 2×1.1 | 1000 | 2740x2510x1980 | 160 |
