Grain Multideck Rotary Cleaner

Product Description
Multideck Rotary Cleaner is particularly suitable for large capacity granular material cleaning and grading to remove large and small impurities. It is also widely used in grain, feed, food, chemical and liquor making industry.

We're here to help: Easy ways to get the answers you need.

Share With:

inquery

  • Tel:+86 16627863527
  • Fax:+86 0371 26811388
  • Email:andy@aohuamachine.com
  • Add:Chenliu, Xiangfu Distirct, Kaifeng City, China
contact us

hot products

  • Maize Mill Equipment

  • Rice Mill Machine

  • Plansifter

  • Double Bins Plansifter

  • 1
  • 2
  • 3
  • 4

description

Multideck Rotary Cleaner
Product Description

1. Large effective screening area, high yield, and good cleaning and grading effect;

2. Combined hanger rod for sieve body suspension, good operation balance, low noise;

3. The feed end is equipped with multiple uniformly distributed material distributor, which can evenly distribute the material to all layers of screen decks,
to ensure the sifting and grading efficiency.

4. Metal screen fram with small metal mesh thickness, high strength and stiffness, and flat screen

5. The screen frame side plate and screen body side plate are fixed by bolts, so that the screen frame and screen

box are integrated by themselves.

6. Easy and convenient assembly and disassembly of screen deck, same mesh interchangeable

7. Modular structure of transmission, complete replacement, saving maintenance time;

8. Low dynamic power consumption.



Technical parameter:
Technical parameter

Name

Super Fine Grain cleaner machine

Model

/

AHZHS150*200/8

AHZHS200*200/8

Capacity

T/H

120

150

Power

KW

3+0.75

Impurity Removal Rate

light

≥99%

≥99%



Heavy

≥94%

≥94%

Weight

KG

6100

7100

Dimension

mm

3462*2445*3892

3462*2945*3892

Remarks

The capacity is based on the wheat(water content about 14%, wheat’s impurities rate ≤8%).

Packaging & Shipping

1. Inner packing: Plastic film

2. Outside packing: container/wooden box
3. Shipping: by sea in QINGDAO port or according to your demand
