Wheat Color Sorter

Product Description
The machine is of high intelligencec, large production(10-2t/h), excellent performance, smooth running, and especially good at eliminating many kinds of defects.

We're here to help: Easy ways to get the answers you need.

Share With:

inquery

  • Tel:+86 16627863527
  • Fax:+86 0371 26811388
  • Email:info@aohuamachine.com
  • Add:Chenliu, Xiangfu Distirct, Kaifeng City, China
contact us

hot products

  • 15TPD RICE MILL MACHINE

  • Maize Mill Equipment

  • Plansifter

  • Double Bins Plansifter

  • 1
  • 2
  • 3
  • 4

description

 Wheat Color Sorter


1. 2048 pixels high-sensitivity CCD sensor with professional processing algorithms, very good image quality with extremely low noise, thus the defects can be easily identified. it's  especially suitable for eliminating mildewed and spotted wheat, mouse droppings, seeds, small stones and other impurities.
2. The LED lamps with special wavelength have very long life(more than three years). it uses patented technology to reduce working noise. The LED lamps have good stability and are cost-effective.
3. New generation high-speed single ejector, frequency up to 1100hz above, fast switching speed, precise control without air tail, high hitting accuracy, low bring out, less air consumption, large production, and long life(more than 1 billion times, insurable with three year).
4. Large chute with special treatment on the surface, smooth wear, so wheat is not easy to jump to ensure the stability of the color sorting effect, The smooth chute can also reduce the carry out.
5. A well-designed Human interface, intelligent, powerful, clearly structured with 3 grade password. The "one -key intelligent adjustment" function is very user-friendly, simple and easy to use.
6. The machine has greatly enhancing system reliability. it uses many international brand-name parts, designed with optimized circuits, manufactured with advanced arts and crafts, it has intelligent on-board monitoring system such as temperature, voltage, current, ejector working state, etc.



type QW4 QW5 QW6 QW7
channels 320 400 480 560
capacity(t/h) 8-14 10-16 12-20 14-24
sorting accuracy(%) >99.98 >99.98 >99.98 >99.98
optimized carryover(bad:good) >8:1 >8:1 >8:1 >8:1
power(kw) 2.2 2.6 2.8 3.0
chutes with heater(kw) 1.0 1.3 1.5 1.8
input voltage(v) 220V 220V 220V 220V
air pressure(mpa) 0.6-0.8 0.6-0.8 0.6-0.8 0.6-0.8
air consumption(m3/min) <2.4 <3.0 <3.6 <4.2
weight(kg) 1120 1200 1330 1480
dimension L*w*H(mm) 2050*1510*1910 2390*1510*1910 2730*1510*1910 3070*1510*1910


1. Inner packing: Plastic film
2. Outside packing: container/wooden box
3. Shipping: by sea in QINGDAO port or according to your demand
